What is a Switch in a Network? Definition, Types, and Functions

In networking, a switch is an important device responsible for the transmission of information between devices.

What is a Switch in a Network? Definition, Types, and Functions
20 Jan

What is a Switch in a Network? Definition, Types, and Functions

In networking, a switch is an important device responsible for the transmission of information between devices. Irrespective of whether it is a small office network or a big data center, knowing what a switch is, what it is used for and how it operates is likely to go a long way in enhancing the efficiency of the network. In this blog, we shall investigate what a switch is, its types, and the roles it plays in a computer network.



What is a Switch in Networking?

what is switch image in webp format

This is a network hardware device that connects computers, printers, servers, and other devices connected within a Local Area Network, known as LAN. This device enables reciprocal communication by accepting data sent in the form of packets, processing them, and sending them to the required device. A switch is therefore important in organizing the flow of traffic within a network.

In contrast to hubs that send all the received data to all the devices on the network, switches transfer the data to the appropriate device only. This means less data is lost due to improved network performance, reducing data traffic that is not necessary.



 Several types of network switches exist. Each of them is intended for a certain purpose. Let us examine in detail the most basic ones:

Unmanaged Switches

Quite simple devices called unmanaged switches can help you join multiple networked devices. These plug-and-play devices are mostly utilized in minimalistic home networks and uncomplicated business environments. These devices are self-operated and do not call for any physical input once connected. They do not offer much functionality but are adequate in connecting many devices.

Managed Switches

Network overseers are accorded the latitude to add, amend and manage as well as supervise the operation of the network using managed switches. It contains features like VLAN and QoS and the ability to monitor the network used in cases of intricate networks.

Layer 2 Switches

Layer 2 switches function in OSI layer 2, also known as the data link layer. These types of switches send data packets after filtering them by MAC addresses, hence appropriate for internal traffic control of Local Area Networks.

Layer 3 Switches

A layer three switch operates on the data link layer and the network layer, making it possible to route data through another network. This capability distinguishes them from layer 2 switches therefore, such switches are commonly used in sophisticated networks for better traffic management between various subnets.

PoE (Power over Ethernet) Switches

PoE switches can provide power through the same Ethernet cables as all the connecting devices, say, IP cameras, and VoIP phones. These switches are beneficial in cases where it becomes impossible to have power outlets beside each device.



Functions of a Switch in a Network

functions of switch in webp format

A switch follows several essential operations, which enable the network to be efficient:

Data Packet Forwarding

The switches act as the forwarding units for the data packets sent from the source device to the destination device by stripping its MAC address and issuing data to the appropriate port. This reduces the inefficient utilization of the network resources.

MAC Address Learning

The switches contain storage in the form of MAC tables where all MAC addresses of the networked devices are attributed to the correct port. The MAC addresses of devices that are attached to the switches are acquired by switches as packets are coming through making it easy to forward non-broadcast packets to the relevant device.

Networking Bottlenecks Reduction

Switches, by forwarding the signal to only the targeted device, enhance network performance by minimizing unnecessary traffic. This allows for better and more efficient communication, particularly over extensive networks.

VLAN function

Network switches can construct virtual networks, thereby storing similar groups of devices optimally and utilizing their resources to their extreme.

Full-Duplex Operation

Full-duplex communication simply means simultaneous sending and receiving of data instead of relying on a single direction transmission, thereby commanding two-fold generation of the effective bandwidth as compared to half which duplex systems such as hubs.

Read More:-Software-World of Technology: Evolutionary History, types and application.

Why are Switches Important in Networking?

Switches are especially important cabling components for increasing network efficiency and security. Having proper traffic control laws minimizes instances of packet collision which enables faster delivery of data. On top of those capabilities, in huge networks, switches can further provide liability to segment networks through VLANs and guarantee a specific level of service which simplifies the brutal architectures in defense advanced network systems.

Conclusion

To conclude, the necessity of a switch in the Network is hardly an exaggeration since it is concerned with the flow management from one another, decreasing the occurrence of over congestion and making the system more efficient. Knowing about the diverse types of switches in terms of their level of management, from the simplest unmanaged and managed switches to the more complex Layer 3 switches will aid you in meeting your desired networking requirements.
